- Years of Manufacture: 1968 - 1969
- Number Built: 79,290 (including GT)
- Price at Introduction:
- Falcon Sedan: $2230
- Fairmont Automatic Sedan: $3171
- Fairmont Wagon: $3381
- Models:
- Falcon Sedan
- Falcon 500 Sedan
- Fairmont Sedan
- GT Sedan
- Station Wagon
- 500 Station Wagon
- Fairmont Station Wagon
- Utility
- 500 Utility
- Van
- Date of Introduction:
- To Identify:
- Minor facelift to previous XR model, with continuation of XR's inspired "Mustang" body
- Carry-over circular tail-lights feature new horizontal centre light
- Plainer (thus flatter looking) horizontal grille treatment without previous XR's 3 horizontal centre bars, and in doing so creating a better illusion of extending beyond headlights, thereby creating a more integrated and unified look
- Body:
- Unitary construction (Monocoque)
- Exterior Dimensions:
- Total Length: 184.6 inches (4689mm)
- Total width: 73.8 inches (1875mm)
- Height at kerb weight: 54.7 inches
(1389mm)
- Wheelbase: 111.0 inches (2819mm)
- Front Track: 58.0 inches (1473mm)
- Rear Track: 58.0 inches (1473mm)
- Kerb Weight:
- Fuel Tank:
- 16.4 gallons (74.6 litres)
- Turning Circle:
- Instruments:
- Speedometer
- Odometer
- Petrol gauge
- Temp gauge
- Oil warning lamp
- Alternator warning lamp
- Transmission:
- Manual
(Six)
- 1st: 2.95:1
- 2nd: 1.68:1
- 3rd: 1.00:1
- Reverse: 3.80:1
- Manual (V8)
- 1st: 2.71:1
- 2nd: 1.69:1
- 3rd: 1.00:1
- Reverse: 3.47:1
- 3S Automatic
- 1st: 2.39:1
- 2nd: 1.45:1
- 3rd: 1.00:1
- Reverse: 2.09:1
- Cruisomatic Auto
(top speed indicated for 302 V8)
- 1st: 2.39:1 to top speed
of 50 mph (80 km/h)
- 2nd: 1.45:1 to top speed
of 85 mph (137 km/h)
- 3rd: 1.00:1 to top speed
of 107 mph (172 km/h)
- Reverse: 2.09:1
|
- Clutch:
- Single cushion disc, dry plate clutch
- Rear Axle Ratio:
- 188ci Six and all Six Automatics: 3.50:1
- 221ci Six Manual: 3.23:1
- V8: 2.93:1
- Engine/Transmission Combinations:
- 188 Six available with manual or 3 speed 3S automatic
- 221 Six available with manual, 3 speed 3S automatic or Cruisomatic
- 302 V8 available with manual or Cruisomatic
- 0-60 mph (0-97 km/h):
- 10.1 seconds (302 V8 Cruisomatic)
- Standing Quarter Mile (400 metres):
- 17.2 seconds (302 V8 Cruisomatic)
- 188 Six:
- Capacity: 188 cubic inches
(3.10 litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
6 cylinders
- Configuration: Front mounted, longitudinal,
inline
- Head: Pushrod and rocker actuated ohv
with two valves per cylinder
- Fuel System: Single throat
downdraft type carburettor
- Bore and Stroke: 3.68 x 2.94 inches
(93 x 75mm)
- Power: 114bhp (85kw) at 4400rpm
- Torque: 180lb-ft (244Nm) at 2400rpm
- Compression Ratio: 9.2:1
- 221 Six:
- Capacity: 221 cubic inches
(3.60 litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
6 cylinders
- Configuration: Front mounted, longitudinal,
inline
- Head: Pushrod and rocker actuated ohv
with two valves per cylinder
- Fuel System: Single throat
downdraft type carburettor
- Bore and Stroke: 3.68 x 3.46 inches
(93 x 88mm)
- Power: 135bhp (101kw) at 4400rpm
- Torque: 208lb-ft (258Nm) at 2400rpm
- Compression Ratio: 9.3:1
- 302 "Mustang" 5 Litre V8:
- Capacity: 302 cubic inches
(4.95 litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
8 cylinders in vee
- Configuration: Front mounted, longitudinal,
inline
- Head: Pushrod and rocker actuated ohv
with two valves per cylinder
- Fuel System: Two barrel carburettor
- Bore and Stroke: 4.00 x 3.00 inches
(102 x 76mm)
- Power: 210bhp (157kw) at 4600rpm
- Torque: 300lb-ft (407Nm) at 2600rpm
- Compression Ratio: 9.0:1
- Ignition and Electrical:
- 12 volt
- Coil and alternator
- Exhaust:
- Six Cylinder: Single tail-pipe, zinc annealed
type muffler
- 289 V8: Twin pipes
- Suspension:
- Front: Independent
type with coil springs and hydraulic double acting shock absorbers, stabiliser bar
- Rear: Live axle, semi-elliptic springs with hydraulic double acting shock absorbers
- Steering:
- Recirculating ball, ratio 14:1
- Optional power steering, ratio 16:1
- Brakes:
- Front: Hydraulic 10 inch (254mm) drums
- Note: Power assisted 10.75 inch (273.05mm) Girling disc brakes standard on Fairmont Six, 11.00 inch (279.40mm) standard on Fairmont V8
- Rear: Hydraulic 10 inch (254mm) drums
- Wheels:
- Pressed steel disc wheels with safety rims
- Tyres:
- Six Sedans: 6.45 x 14 four-ply
- V8 Sedans: 7.35 x 14 four-ply
- Wagons, Utilities and Vans: 185 x 14 four-ply
- Note: Radials optional on all models
